Spray Ball / Device for CIP Systems | Food Manufacturing Component

Product Specifications

Technical details and manufacturing context for Spray Ball / Device

Definition

A spray ball or spray device is a critical component within a Clean-in-Place (CIP) system, designed to be installed inside process vessels, tanks, or pipelines. Its primary function is to receive pressurized cleaning and sanitizing solutions from the CIP unit and distribute them as a spray pattern (typically full 360° coverage) to effectively wet, clean, and rinse all internal surfaces without requiring manual intervention or disassembly of the equipment. The device is typically made of stainless steel (AISI 304/316L), PTFE, or food-grade plastics, and is available in fixed or rotating configurations. In fixed models, the orifice pattern is engineered to create overlapping spray coverage, ensuring complete surface contact. In rotating models, the reaction force from the exiting jets causes the ball to rotate, changing the spray direction and enhancing coverage. The operating pressure range is 1.0–1.6 MPa, with a flow rate of 5–20 m³/h depending on tank size and nozzle type. Spray coverage diameter is 1–5 m for tanks up to 5 m diameter. Operating temperature ranges from -20°C to 140°C for CIP cleaning with hot water and caustic. The material for food contact is typically 316L stainless steel (ASTM A240), with surface roughness ≤0.8 μm Ra (ISO 4287) for hygienic design. Connection sizes range from DN25 to DN100 (ISO 1127), with tri-clamp or welded connections. Weight varies from 0.5 to 5 kg depending on size and material. Rotating spray balls operate at 10–30 rpm. The device is rated IP65–IP68 for washdown environments. These parameters are reference ranges and must be verified for the specific model and application with the legal manufacturer or supplier. The spray ball is essential for effective cleaning in food manufacturing, ensuring hygiene and product safety.

Working Principle

Pressurized cleaning fluid (water, detergent, acid, caustic, or sanitizer) is pumped from the CIP unit through a supply line into the spray ball. The fluid exits through precisely designed orifices or slots. In rotating models, the reaction force from the exiting jets causes the ball to rotate, changing the spray direction. In fixed models, the orifice pattern is designed to create overlapping spray coverage. This ensures complete surface contact for mechanical removal of soil and chemical action.

Common Materials

Stainless Steel (AISI 304/316L), PTFE (Teflon), Food-Grade Plastics

Technical Parameters

Parameter	Typical range	Notes & selection driver
Flow Rate	5–20 m³/h	Depends on tank size and nozzle type
Spray Coverage Diameter	1–5 m	For tanks up to 5 m diameter
Operating Temperature	-20–140 °C	For CIP cleaning with hot water and caustic
Material	316L	Stainless steel for food contactASTM A240
Surface Roughness	≤0.8 μm Ra	For hygienic designISO 4287
Connection Size	DN25–DN100	Tri-clamp or weldedISO 1127
Weight	0.5–5 kg	Depends on size and material
Rotation Speed	10–30 rpm	For rotating spray balls
IP Rating	IP65–IP68	For washdown environmentsIEC 60529

Ranges are indicative industry figures for RFQ preparation, not a supplier commitment. Confirm every value and standard with the legal manufacturer before ordering.

Components / BOM

Housing/Body Part
Main structural body containing internal fluid passages and providing connection to the supply line.

Material: Stainless Steel 316L
Orifice Plate/Nozzle Head Part
The front section containing the precisely drilled holes or machined slots that form the spray pattern.

Material: Stainless Steel 316L
Seal/Gasket Part
Ensures a leak-proof connection between the spray ball and the vessel port or mounting flange.

Material: EPDM, Silicone, or PTFE
Bearing (for rotating types) Optional Part
Allows low-friction rotation of the ball under fluid pressure.

Material: Stainless Steel or Ceramic

Industry Taxonomies & Aliases

Commonly used trade names and technical identifiers for Spray Ball / Device.

Applied To / Applications

This component is essential for the following industrial systems and equipment:

CIP System

View system integration details

Manufacturers of Spray Ball / Device
