Technical Definition & Core Assembly

A precision mounting system designed to securely position and orient antennas within an EMI shielding test chamber for accurate electromagnetic interference testing.

View Full Specifications Explore Manufacturing Sources
Internal Antenna Mounting System in a manufacturing environment
Representative product image. Confirm appearance and specifications with the manufacturer.

Product Specifications

Technical details and manufacturing context for Internal Antenna Mounting System

Definition
The Internal Antenna Mounting System is a critical component of Industrial Electromagnetic Interference (EMI) Shielding Test Chamber Systems, providing precise, adjustable, and stable positioning for various antenna types used in electromagnetic compatibility (EMC) testing. It ensures repeatable antenna placement for consistent measurement results while maintaining the chamber's shielding integrity. The system is constructed from materials such as aluminum alloy, stainless steel, and non-conductive composite materials, ensuring durability and minimal interference. It supports a frequency range of 30 MHz to 18 GHz, covering typical EMC test bands, and accommodates antennas with gains from 0 to 10 dBi. The system achieves a VSWR of ≤2.0, ensuring low reflection, and offers positioning accuracy of ±0.5 mm for repeatable test setups. Angular resolution of 0.1° allows fine adjustment for polarization. The load capacity ranges from 5 to 15 kg, supporting various antenna sizes. Operating temperature ranges from -40 to 85 °C, and relative humidity from 0 to 95% (non-condensing), making it suitable for environmental chambers. The material is specified as aluminum alloy 6061-T6 per ASTM B211, with a surface finish of 8–12 μm Ra per ISO 1302. The system weighs between 2.5 and 4.0 kg, and its dimensions are 300×200×150 mm (L×W×H). These parameters are reference ranges and must be verified for the specific model and application. The system is designed for use in EMI shielding test chambers, and its performance should be confirmed with the legal manufacturer or supplier. Always verify model-specific values and standards before procurement or use.
Working Principle
The system utilizes adjustable mounting brackets, rails, or arms with precise positioning mechanisms (manual or motorized) to place antennas at specific locations and orientations within the test chamber. It maintains electrical isolation from the chamber walls to prevent interference with measurements and allows for quick reconfiguration between different test setups. The positioning mechanisms enable fine adjustments in translation and rotation, ensuring accurate antenna placement. The system's design minimizes reflections and maintains shielding integrity, contributing to reliable EMC testing.
Common Materials
Aluminum alloy, Stainless steel, Non-conductive composite materials
Technical Parameters
ParameterTypical rangeNotes & selection driver
Frequency Range30 MHz–18 GHz MHz/GHzCovers typical EMC test bands
Antenna Gain0–10 dBiDepends on antenna type
VSWR≤2.0Ensures low reflection
Positioning Accuracy±0.5 mmFor repeatable test setups
Angular Resolution0.1 °Fine adjustment for polarization
Load Capacity5–15 kgSupports various antenna sizes
Operating Temperature-40–85 °CSuitable for environmental chambers
Relative Humidity0–95 % RHNon-condensing
Material6061-T6Aluminum alloy, corrosion resistantASTM B211
Surface Finish8–12 μm RaSmooth for EMI shieldingISO 1302
Weight2.5–4.0 kgLightweight for easy handling
Dimensions (L×W×H)300×200×150 mmCompact footprint

Ranges are indicative industry figures for RFQ preparation, not a supplier commitment. Confirm every value and standard with the legal manufacturer before ordering.

Components / BOM
  • Mounting Base Plate Part
    Provides stable foundation and attachment points to chamber structure
    Material: Aluminum alloy
  • Vertical Support Column Part
    Enables height adjustment of antenna positioning
    Material: Aluminum alloy
  • Horizontal Positioning Arm
    Allows horizontal movement and positioning of antenna
    Material: Aluminum alloy
  • Antenna Clamping Mechanism
    Securely holds various antenna types without damaging them
    Material: Non-conductive composite
  • Angular Adjustment Joint
    Provides precise angular orientation control for antenna
    Material: Stainless steel
  • Position Locking Mechanism
    Secures antenna in position once desired location is achieved
    Material: Stainless steel
  • Electrical Isolation
    Keeps the mount electrically separate from the chamber wall so it does not disturb the measurement.
  • Motorized Positioning Unit Optional
    Drives the antenna to position remotely on motorized versions instead of by hand.
