Technical Definition & Core Assembly

A component within a Thermal Control Unit responsible for generating or removing heat to regulate temperature.

View Full Specifications Explore Manufacturing Sources
Representative product image. Confirm appearance and specifications with the manufacturer.

Product Specifications

Technical details and manufacturing context for Heating/Cooling Element

Definition
The Heating/Cooling Element is a critical part of Thermal Control Units that actively produces heat (via electrical resistance, combustion, or other methods) or absorbs heat (via refrigeration cycles, thermoelectric effects, or phase change materials) to maintain precise temperature conditions in industrial processes, equipment, or environments. This component is designed for integration into larger systems, where it operates under the control of sensors and feedback mechanisms to achieve and maintain target temperatures. Typical applications include temperature regulation in industrial machinery, process equipment, and environmental control systems. The element is available in configurations that support heating capacities from 0.5 to 100 kW and cooling capacities from 0.5 to 80 kW, with an operating temperature range of -40°C to 85°C. It operates at pressures from 1.0 to 1.6 MPa and requires a 24 V DC supply (±10%). Power consumption is up to 150 W at full load, and temperature control accuracy is ±0.5°C under stable conditions. Response time to reach 90% of setpoint is ≤10 seconds. The element is offered with ingress protection ratings from IP54 to IP65 (per IEC 60529) and is constructed from corrosion-resistant stainless steel (grade 316L per ASTM A240). Weight ranges from 5 to 50 kg, and dimensions vary from 300×200×150 mm to 800×600×400 mm. These specifications are reference ranges; actual values must be confirmed with the manufacturer for the specific model and application. The element is a component, not a standalone system, and its performance depends on proper integration, control, and maintenance.
Working Principle
The Heating/Cooling Element operates by converting electrical energy into thermal energy for heating, or by using thermodynamic cycles to transfer heat away for cooling. In heating mode, electrical resistance or combustion generates heat. In cooling mode, refrigeration cycles, thermoelectric effects, or phase change materials absorb heat. Sensors and feedback systems regulate the element's output to maintain the desired temperature. The element's response time and accuracy are critical for precise temperature control.
Common Materials
Stainless Steel, Copper, Aluminum, Ceramic, Nickel-Chromium Alloy
Technical Parameters
ParameterTypical rangeNotes & selection driver
Heating Capacity0.5–100 kWSelect based on required temperature rise and flow rate
Cooling Capacity0.5–80 kWSelect based on heat load to be removed
Operating Temperature Range-40–85 °CBeyond this range, performance degrades
Supply Voltage24 ±10% V DCOther voltages available on request
Power Consumption≤150 WMaximum at full load
Temperature Control Accuracy±0.5 °CUnder stable conditions
Response Time≤10 sTime to reach 90% of setpoint
Ingress ProtectionIP54–IP65Higher IP for dusty or wet environmentsIEC 60529
Material316LCorrosion-resistant stainless steelASTM A240
Weight5–50 kgDepends on capacity and configuration
Dimensions (L×W×H)300×200×150–800×600×400 mmVaries with capacity

Ranges are indicative industry figures for RFQ preparation, not a supplier commitment. Confirm every value and standard with the legal manufacturer before ordering.

Components / BOM
  • Heating Coil Part
    Converts electrical energy to heat through resistance
    Material: Nickel-Chromium Alloy
  • Thermoelectric Module
    Creates temperature difference using Peltier effect for cooling
    Material: Bismuth Telluride
  • Heat Exchanger Fins Part
    Increases surface area for efficient heat transfer
    Material: Aluminum
  • Insulation Layer Part
    Prevents heat loss/gain and protects surrounding components
    Material: Ceramic Fiber

Applied To / Applications

This component is essential for the following industrial systems and equipment:

Thermal Control Unit
View system integration details
Thermal Shelf
View system integration details
Sample Conditioning Chamber
View system integration details

Industrial Ecosystem & Supply Chain Structure

Complementary Systems
Downstream Applications
Specialized Tooling

Application Fit & Sizing Matrix

Operational Limits
pressure: 0 to 10 bar
flow rate: 0.5 to 20 L/min
temperature: -50°C to +300°C
slurry concentration: Up to 15% solids by weight
Media Compatibility
✓ Water/Glycol mixtures ✓ Thermal oils (e.g., silicone, mineral) ✓ Process gases (air, nitrogen)
Unsuitable: Corrosive chemicals (e.g., strong acids, chlorides)
Sizing Data Required
  • Required thermal power (kW)
  • System operating temperature range (°C)
  • Media flow rate (L/min)

Reliability & Engineering Risk Analysis

Failure Mode & Root Cause
Thermal fatigue cracking
Cause: Repeated heating and cooling cycles causing expansion/contraction stresses, leading to crack initiation and propagation in the element material
Corrosion and scaling
Cause: Chemical reactions with process fluids or environmental exposure, resulting in material degradation and insulating deposits that reduce heat transfer efficiency
Maintenance Indicators
  • Visible discoloration, warping, or hot spots on the element surface during operation
  • Audible popping, cracking, or sizzling sounds indicating rapid thermal expansion or moisture intrusion
Engineering Tips
  • Implement controlled ramp-up and cool-down procedures to minimize thermal shock and stress accumulation
  • Establish regular descaling and corrosion inspection protocols based on fluid chemistry analysis and operating hours

Indicative industry ranges for design and RFQ preparation. Confirm the exact figures and applicable standard with the manufacturer before specifying.

Compliance & Manufacturing Standards

Applicable Standards
IEC 60335-1 - Safety of household and similar electrical appliances ASTM B88 - Standard Specification for Seamless Copper Water Tube

Quoted from the published standard.

Manufacturing Precision
  • Resistance: +/-5% of nominal value
  • Surface flatness: 0.1mm per 100mm length
Quality Inspection
  • Insulation resistance test (minimum 100 MΩ at 500V DC)
  • Leakage current test (maximum 0.75 mA at rated voltage)
