Control Valve Block

Based on aggregated insights from multiple verified factory profiles within the CNFX directory, the standard Control Valve Block used in the Machinery and Equipment Manufacturing sector typically supports operational capacities ranging from standard industrial configurations to heavy-duty production requirements.

Technical Definition & Core Assembly

A canonical Control Valve Block is characterized by the integration of Solenoid Valve and Pressure Regulator. In industrial production environments, manufacturers listed on CNFX commonly emphasize Aluminum alloy construction to support stable, high-cycle operation across diverse manufacturing scenarios.

A modular assembly of valves and ports that regulates fluid flow and pressure in gripper head systems.

View Full Specifications Explore Manufacturing Sources

Product Specifications

Technical details and manufacturing context for Control Valve Block

Definition
A control valve block is a compact, integrated manifold system within a gripper head (vacuum pad/mechanical claw) that centralizes the control of pneumatic or hydraulic circuits. It manages the actuation, release, and pressure regulation for gripping operations, ensuring precise and reliable manipulation of objects.
Working Principle
The valve block receives compressed air or hydraulic fluid from a supply line and distributes it through internal passages to individual valves. Solenoid or manual valves within the block open/close to direct flow to the gripper's actuators (e.g., vacuum pads or mechanical fingers), controlling grip, release, and force. It may include regulators, flow controls, and pressure sensors for fine-tuning.
Common Materials
Aluminum alloy, Stainless steel, Brass
Technical Parameters
  • Port size (e.g., G1/8, 1/4 NPT) and overall block dimensions (mm) Customizable
Components / BOM
  • Solenoid Valve
    Electrically actuated valve to control flow direction
    Material: Brass/Stainless steel
  • Pressure Regulator
    Adjusts and maintains output pressure to the gripper
    Material: Aluminum/Stainless steel
  • Manifold Body
    Main block structure with internal fluid passages
    Material: Aluminum alloy
Engineering Reasoning
0.5-15.0 bar
18.7 bar (Burst pressure at 150% of maximum working pressure)
Design Rationale: Plastic deformation of valve seat material (PTFE) due to exceeding yield strength of 23 MPa at 18.7 bar differential pressure
Risk Mitigation (FMEA)
Trigger Particulate contamination exceeding 25 μm in hydraulic fluid
Mode: Valve seat erosion leading to 0.3 L/min internal leakage
Strategy: Install 10 μm absolute filtration with differential pressure monitoring at 0.5 bar threshold
Trigger Solenoid coil temperature exceeding 130°C for 30 minutes
Mode: Insulation breakdown causing 5.6 mA ground fault current
Strategy: Integrate PTC thermistor protection with 125°C trip point in coil winding

Industry Taxonomies & Aliases

Commonly used trade names and technical identifiers for Control Valve Block.

Valve Manifold Pneumatic Valve Block modular control valve block gripper head aluminum alloy control valve assembly fluid pressure regulator solenoid valve machinery equipment valve manifold stainless steel brass valve block

Applied To / Applications

This component is essential for the following industrial systems and equipment:

Gripper Head (Vacuum Pad/Mechanical Claw)
View system integration details
